Puretec FP10B Heavy Duty Filter Housings

Puretec FP Series Heavy Duty Filter Housings
Versatile, heavy duty water filter housing for up to 76 litres/minute. The unique advantage with this versatile range of housings isthat they are both compact and durable enough to use anywhere in so many different situations, whether it be at home, work or in industrial processes. The FP Series are capable of pressures up to 875 kPa at 52°C and accept a broad range of Puretec cartridges to suit your requirements. Clear bowl housings are rated to 350 kPa and ideal for monitoring filter condition, but must be protected from direct sunlight to prevent bacterial growth.

SPECIFICATIONS
Model Number: FP10B
Size (Inches): 10″
Description: Filter housing kit with grey bowl. Includes spanner wrench and mounting bracket.
Connection: ¾” (20mm)
Min/Max Temp: 0-52°C
Min/Max Pressure: 0-875 kPa
Min/Max Flow: 0-38 Lpm
Dimensions (mm): 115 x 307

FEATURES & BENEFITS
• Compact, durable, economical design
• Quick and easy installation
• Compact and economical, ideal for duplex systems
• Internal and external use to suit different applications
• Ribbed design provides a robust housing for years of trouble
free service
• Available in 10” and 20” heights
• Suitable for flow rates up to 76 litres per minute

MATERIALS OF CONSTRUCTION
• Housing: Polypropylene, Styrene Acrylonitrile (Clear)
• Cap: Reinforced Polypropylene
• O-Ring: Buna-N
• Maximum Temperature: 52°C
• Maximum Pressure: 875 kPa for Polypropylene, 350 kPa for Clear Housings
